The V-R653SB-IMD is a triple 6.5" LCD monitor with HD-SDI inputs and In-Monitor Display functionality – a cost-effective "all-in-one" solution for post-production houses, broadcasters, and mobile units. This fully integrated approach eliminates the need for additional or separate Under Monitor Displays and allows UMD information and tallies to be displayed directly within a Marshall flat panel monitor, while saving precious rack space. A variety of features are readily available including on-screen Video Time Code, three-color "Soft" Tallies, Audio Presence Indicator, and a new RotoMenu™ feature that allows fast, direct, and easy menu navigation.


V-R653SB-IMD

Triple 6.5" HD/SD 1024 x RGB x 768 Rack Mounted Super Transflective Outdoor Monitor Set with HD-SDI / SDI inputs and In-Monitor Display features

optional network controller box logo

In Monitor Display logo

Owner's Manual (PDF)
V-R653SB-IMD Super Transflective Outdoor LCD Rack Monitor
  • No need for external Under Monitor Display -- "all-in-one" In-Monitor Display
    solution without added depth
  • Supports the following protocols:
    Image Video / NVISION / TSL / MEI
  • High Resolution 1024 x 768 RGB Dots
    with 2.4 million pixels
  • New unique RotoMenu™ for fast, direct,
    and easy menu navigation
  • 5 Year / 50,000 hour backlight life
  • High resolution scaling / high quality deinterlacing
  • 650 cd/m² luminance produces enhanced image quality in varying light and viewing conditions
  • 500:1 ratio of contrast between black and
    white luminance values
  • Three-color on-screen "soft" tally indicators
    (Red / Green / Amber)
    Super Transflective Outdoor Monitor
  • 16.7 million colors
  • Three LED color tally indicators
    (Red / Green / Amber)
  • On-Screen Audio Presence Indicator
  • On-Screen Video Time Code
  • RS-422 / 485 connection with loop-through
    for control communication / IMD functionality
  • Field upgradeable firmware capability
    via RS-422 / 485 port
  • Direct access for adjustments of brightness,
    contrast, and color
  • Multiple Frame Marker Overlays with Center Mark
  • Pixel-to-Pixel mode
  • Blue Gun for color adjustment
  • Adjustment Settings Memory

Marshall Electronics introduces the industry's first full lineup of LCD panels with In-Monitor Display functionality. The new V-R653SB-IMD triple HD / SD 6.5 monitor set is a cost-effective "all-in-one" solution for post production houses, broadcasters, and mobile units. This fully-integrated approach eliminates the need for additional or separate Under Monitor Displays and allows UMD information and tallies to be displayed directly within a Marshall flat panel monitor, while saving precious rack space. A variety of features are readily available including on-screen Video Time Code, three-color "Soft" Tallies, and Audio Presence Indicator. This Marshall IMD display also introduces our new RotoMenu™ feature which allows fast, direct, and easy menu navigation.

Marshall's IMD monitors integrate easily with existing Tally systems and controllers, including Image Video, NVISION, TSL, and MEI (Marshall Electronics) protocols. This 4RU unit also ships ready to rack mount and provides up to 20% more screen when compared to our competitors' LCD and CRT models that occupy the same space. This is in addition to the benefits of low weight and power consumption when compared to similar CRT products and separate Under Monitor Display configurations. The V-R653SB-IMD is a perfect solution for large Video Wall applications and systems.

Each screen offers a single HD-SDI/SDI input with active loop-through capability. Additional features include adjustment settings memory, multiple Frame Marker Overlays, Blue Gun, Pixel-to-Pixel mode, and direct access for adjustment and selection functions. Can also be used as standalone displays with HD-SDI loop-through.

Super Transflective Outdoor Monitors

Super Transflective Outdoor Monitors

Marshall Electronics offers a full line of Super Transflective Outdoor Monitors, designed specifically for outdoor applications with high ambient light. Our technology minimizes surface reflection of both outdoor and indoor light, while featuring a much wider color reproduction range than typical transflective/reflective LCDs or even those with increased backlight performance.

These outdoor super-transmissive LCDs provide improved visibility by producing high-contrast images and a wider viewing angle, even under diverse and challenging lighting environments! This innovative technology dramatically boosts the efficiency of the LCD backlight's light utilization, while maintaining extended temperature ratings and low power consumption for outdoor operation.


V-R653SB-IMD SPECIFICATIONS
Display (Viewing Area) (3) 6.5-inch diagonal (132.096mm W x 99.072mm H)
Resolution (RGB Dots) 1024 W x RGB x 768 V (16.7 Million colors)
Viewing Angles 160° H x 140° V
Dot Pitch 0.043 (H) x 0.129 (V) mm
Contrast Ratio 500:1
Brightness (in cd/m²) 650
Dimensions 19" W x 5.3" H x 2.6" D
Weight 5.45 lbs
System NTSC/PAL auto recognition
APPLICATIONS
  • Studio Monitor Wall
  • Remote/OB Van
  • EFP/ENG
  • Fly Packs
  • Camera Shading
